XM-A3E1-0404D
XR-A3E1-0404D RoHS
Amplifier, HMC1040LP3CE [PCB: 0278]
F=24-43.5GHz
Recommended Bias Controller: XM-A2J7-0404D-SP
Product Page |
N/A ADI |
Spec Sheet |
N/A
HMC1040LP3CE |
Low Freq |
N/A 24000 MHz |
High Freq |
N/A 43500 MHz |
Gain |
N/A 23 dB |
NF |
N/A 2.2 dB |
P1dB |
N/A 12 dBm |
IP3 |
N/A 22 dBm |
|
|
N/A |
Bias Instruction |
N/A
Power-up Sequence
1. Apply VDD = 2.5V Verify IDD ~70mA 2. Apply RF Input Power-down Sequence 1. Remove RF Input 2. Turn off VDD |
RoHS |
N/A XR-A3E1-0404D |
